A foot-pumped lift table that brings up to 2,000 kg to the working height you need. No electrical supply, nothing to charge, and a simple hydraulic circuit your own fitter can maintain.
The Nandi Hydraulic Manual Scissor Lift is a heavy-duty lifting table for positioning loads in factories, warehouses and production areas. A foot-operated hydraulic pump raises the platform smoothly to the height you need, so there is no electrical supply to arrange and far less bending and lifting for your operators.
Built in Coimbatore with a stout scissor mechanism, a heavy-duty platform and a straightforward hydraulic system, these lifts are made for continuous shop-floor use. Four capacities from 500 kg to 2,000 kg and lift heights up to 1,500 mm cover most jobs where a load has to be raised, held or transferred at a set height.
| Capacity | 500 kg / 1,000 kg / 1,500 kg / 2,000 kg |
| Platform Size | 1,500 × 750 mm |
| Overall Length | 1,500 mm (approx.) |
| Overall Width | 800 mm |
| Lowered Height | 500 mm |
| Max Lift Height | 900 mm / 1,250 mm / 1,500 mm |
| Lifting Method | Manual Hydraulic Pump |
| Movement | Manual |
| Wheel Type | Nylon / Polyurethane / Cast Iron |
| Wheel Size | Ø150 × 50 mm, 4 Nos |
| Finish | Deep Orange, Powder Coated |
For any job that needs load lifting without power: assembly lines, loading bays, maintenance bays and inspection stations.
Raising components and sub-assemblies to a comfortable working height on the line, so operators tire less and fit parts more accurately.
Loading and unloading goods at height and holding palletised stock at pick-face level in stores and despatch areas.
Raising machinery, vehicle parts and heavy components to a comfortable height for servicing and repair in workshops.
Holding products and components at the right height for inspection, measurement and quality checks without manual lifting.
Select the specifications that match your application and we will prepare a quote for that configuration.
