Safe lifting, stacking and movement of loads without pallets or front support legs. Electric drive, powered hydraulic lifting and a counter balanced structure, with lift heights up to 4,500 mm.
NANDI M Battery Operated Counter Balanced Stackers lift, stack and move loads safely without pallets or support legs in front. That makes them the right choice for dies, bins, components, and palletised or non-palletised loads in factories, warehouses and production areas. Electric drive, powered hydraulic lifting and a five-point counter balanced structure give smooth manoeuvring, dependable lifting and better operator safety.
Available as a Single Mast model for lift heights from 500 – 1,600 mm, or a Double Mast Telescopic model reaching 1,600 – 4,500 mm. A ZAPI electronic controller, electromagnetic and regenerative braking, emergency reversing device and emergency power disconnect come as standard, with manual or electronic power steering to choose from. Capacity, lift height, fork width, steering and mast configuration can all be built to your application, backed by ready spare parts and service support.
| Rated Capacity | 500 kg – 2,000 kg |
| Drive Unit | Electric |
| Operating Type | Standing or Pedestrian |
| Lift Height (Single Mast) | 500 – 1,600 mm |
| Lift Height (Double Mast Telescopic) | 1,600 – 4,500 mm |
| Lowered Fork Height | 90 mm |
| Fork Length / Type | 1,200 mm, Forged Fork |
| Movable Fork Width Range | 400 – 750 mm |
| Width of Each Fork | 100 × 40 mm |
| Mast Tilting | 2° – 4° |
| Drive Motor / Pump Motor | 1.5 kW / 2.2 kW |
| Hydraulic Pump | Dowty Gear Pump |
| Battery / Charger | 24V 345Ah / 24V 30A Transformer Type |
| Brake System | Electromagnetic + Regenerative |
| Controller | ZAPI Electronic Controller |
| Steering Options | Manual / Electronic Power Steering |
Built for industrial environments where conventional stackers may not suit: anywhere loads must be lifted, stacked or moved without pallets or front support legs.
Handling dies, bins and industrial components, including non-palletised loads that conventional stackers with front legs cannot reach.
Smooth electric traction for continuous material movement across factory floors, warehouses, and production areas.
Powered hydraulic lifting for fast, low-effort loading and unloading, with the operator kept clear of the load.
Stacking loads at different working heights, up to 4,500 mm with the double mast telescopic model.
Select the specifications that match your application. Our team will prepare a tailored quote based on your configuration.
